Description
Dinstar UC2000-VE-4G GSM/WCDMA/LTE VoIP Gateway Dubai
The Dinstar UC2000-VE-4G Dubai is an advanced and adaptable 4-channel GSM/3G/4G VoIP Gateway engineered on a compact, proven hardware platform to deliver smooth, stable, and uninterrupted communication between mobile networks and VoIP systems for both voice and SMS services. With built-in support for GSM, WCDMA, and LTE technologies, along with full SIP protocol compatibility across major VoIP platforms, this gateway serves as an excellent choice for enterprises, distributed branch networks, call termination operators, and locations where traditional landline infrastructure is limited or unreliable. It effectively lowers telecommunication expenses while enabling reliable, efficient, and user-friendly connectivity. Additionally, the UC2000-VE-4G can function independently or integrate seamlessly with Dinstar SIMBank and SIMCloud for centralized, remote SIM management, offering enhanced flexibility, control, and scalability to suit a wide range of deployment needs.
Features
4-channel VoIP GSM/3G/4G Gateway
- GSM/WCDMA/LTE support
- Voice over LTE (VoLTE)
- Hot Swappable SIM Cards
- Compatible with mainstream VoIP platform
- Mobility Extension, never miss a call
- SMS sending & receiving, SMS API
- Credit Limit management
- Auto CLIP
Applications
- Mobile connectivity for SME IP phone system
- Mobile trunking for Multi-site offices
- GSM/3G as voice backup trunks
- Call termination for service providers
- Land-line replacement for rural area
- Bulk SMS service
- Call Center / Contact Center Solution
Easy Management & Automatic Configuration
- Intuitive Web interface
- Remote SIMs management with Dinstar SIMBank & SIMCloud
- Configuration Backup & Restore
- Advanced Debug tools
Technical Highlights
- 4 SIM slot, 4 antennas
- Signaling & RTP Encryption
- Built-in antennas combiner (Optional)
- SMPP for SMS
- GSM: 850/900/1800/1900Mhz
- HTTP API for SMS
- WCDMA: 900/2100Mhz or 850/1900Mhz
- Polarity Reversal
- LTE: Multiple frequency choices for different countries
- PIN Management
- SIP v2.0, RFC3261
- SMS/USSD
- Codecs: G.711A/U , G.723.1, G.729AB
- SMS to Email, Email to SMS
- Echo Cancellation
- Call Waiting/Call Back
- DTMF: RFC2833, SIP Info
- Call Forward
- Programmable Gain Control
- GSM Audio Coding: HR, FR,EFR, AMR_FR,AMR_HR
- Mobile to VoIP, VoIP to Mobile
- HTTPS/HTTP Web Configuration
- SIP Trunk and Trunk Group
- Configure Backup/Restore
- Port and Port Group
- Firmware Upgrade by HTTP/TFTP
- Caller/Called Number Manipulation
- CDR(10000 Lines Storage Locally)
- SIP Codes Mapping
- Syslog/Filelog
- White/Black List
- Traffic statistics: TCP,UDP,RTP
- PSTN/VoIP Hotline
- VoIP Call Statistics
- Abnormal Call Monitor
- PSTN Call statistics: ASR,ACD,PDD
- Call Minutes Limitation
- IVR Customization
- Balance Check
- Auto Provisioning
- Random Call Interval
- SIP/RTP/PCM Capture
- Auto CLIP
- Work with Dinstar SIMCloud/SIMBank (Optional)
